| Nambari ya Sehemu | TM097QDSP01 |
| Chapa | TIANMA |
| Ukubwa | 9.7 |
| Maombi | Pad & Tablet |
| Azimio | 1536×2048 |
| Muundo | LCM , a-Si TFT-LCD |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 6S6P |
| Kiolesura | MIPI |
| mtengenezaji | TIANMA |
| jina la mfano | TM097QDSP01 |
| ukubwa wa skrini | 9.7 inch |
| aina ya skrini | LCM , a-Si TFT-LCD |
| nambari ya pixel | 1536(RGB)×2048 (QXGA) 264PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 147.456 × 196.608 (H×V) |
| muhtasari(mm) | 154.016 × 207.83 × 3.75 (H×V×D) |
| eneo la bezel(mm) | - |
| matibabu | Hard coating |
| mwangaza | 460 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000 : 1 (Typ.) (TM) |
| angle ya kutazama | 89/89/89/89 (Typ.)(CR≥10) |
| majibu | 25 (Typ.)(Tr+Td) ms |
| mtazamo mzuri | Symmetry |
| hali ya kazi | SFT, Normally Black, Transmissive |
| kina cha rangi | 16.7M 72% NTSC |
| backlight | 6S6P WLED , No Driver |
| wingi | 110g (Typ.) |
| kutumika kwa | Pad & Tablet |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | Without |
| aina ya ishara | MIPI (2 ch, 4 data lanes) , 61 pins Connector |
| usambazaji wa voltage | 1.8/5.0/-5.0V (Typ.)(VDDI/AVDD/AVEE) |
| max. ukadiriaji | Storage Temp.: -30 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
| BF097XN | Innolux | 9.7 | 1024×768 |
| LP097QX1-SPA1 | LG Display | 9.7 | 2048×1536 |
| LP097QX1-SPAV | LG Display | 9.7 | 2048×1536 |
| LP097QX2-SPAV | LG Display | 9.7 | 1536×2048 |
| LP097QX3-SPAV | LG Display | 9.7 | 1536×2048 |
| LP097X02-SLQ1 | LG Display | 9.7 | 1024×768 |
| LQ097L1JY01A | SHARP | 9.7 | 2048×1536 |
| LTN097XL01-A01 | Samsung | 9.7 | 1024×768 |
| TM097TDH01 | Tianma | 9.7 | 1024×768 |
| TM097TDH02 | Tianma | 9.7 | 1024×768 |
