| Nambari ya Sehemu | TM123XDHP90 |
| Chapa | TIANMA |
| Ukubwa | 12.3 |
| Maombi | Industrial Outdoor H |
| Azimio | 1920×720 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 10S4P |
| Kiolesura | LVDS |
| chapa ya paneli | TIANMA |
| mfano wa paneli | TM123XDHP90 |
| saizi ya paneli | 12.3" |
| aina ya paneli | a-Si TFT-LCD, LCM |
| azimio | 1920(RGB)×720, 166PPI |
| muundo wa pixel | RGB Vertical Stripe |
| eneo la maonyesho | 292.32(W)×109.62(H) mm |
| ufunguzi wa bezel | - |
| saizi ya muhtasari | 311(W)×130(H) ×15.7(D) mm |
| uso | Antiglare (Haze 28%) |
| mwangaza | 1000 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000:1 (Typ.) (TM) |
| angle ya kutazama | - |
| hali ya kuonyesha | SFT, Normally Black, Transmissive |
| mwonekano bora zaidi | Symmetry |
| wakati wa majibu | 25 (Typ.)(Tr+Td) |
| kuonyesha rangi | 16.7M 98% sRGB |
| aina ya taa | 10S4P WLED , 10K hours , Without Driver |
| masafa | 60Hz |
| skrini ya kugusa | Without |
| uzito wa paneli | 490g (Typ.) |
| maombi | Industrial Outdoor High Brightness Automotive Display |
| kiolesura cha ishara | LVDS (2 ch, 8-bit) , 50 pins FPC |
| voltage ya pembejeo | 3.3V (Typ.) |
| mazingira | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
