| Nambari ya Sehemu | TMS156WX1-02TC |
| Chapa | Tianma |
| Ukubwa | 15.6 |
| Maombi | DMPC |
| Azimio | 1366×768 |
| Muundo | CELL |
| Mwangaza | 0 |
| CR | 500:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | No B/L |
| Kiolesura | LVDS |
| chapa ya paneli | AVIC |
| mfano wa paneli | TMS156WX1-02TC |
| aina ya paneli | a-Si TFT-LCD , CELL |
| saizi ya paneli | 15.6 inch |
| azimio | 1366(RGB)×768 , WXGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 344.232×193.536 mm |
| uso | |
| uwiano wa utofautishaji | 500:1 (Typ.) |
| kuonyesha rangi | 16.7M (8-bit), CIE193160% |
| wakati wa majibu | 2/6 (Typ.)(Tr/Td) |
| angle ya kutazama | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| kiolesura cha ishara | LVDS (1 ch, 8-bit), 30 pins |
| voltage ya pembejeo | 5.0V (Typ.) |
| maombi | DMPC |
