| Nambari ya Sehemu | TV070WSM-TL1 |
| Chapa | BOE |
| Ukubwa | 7.0 |
| Maombi | Pad & Tablet |
| Azimio | 600×1024 |
| Muundo | Assembly , a-Si TF |
| Mwangaza | |
| CR | 800:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 6S3P |
| Kiolesura | MIPI |
| mtengenezaji | BOE |
| jina la mfano | TV070WSM-TL1 |
| ukubwa wa skrini | 7.0 inch |
| aina ya skrini | Assembly , a-Si TFT-LCD |
| nambari ya pixel | 600(RGB)×1024 (WSVGA) 170PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 89.28 × 152.37 (H×V) |
| muhtasari(mm) | 97 × 188.26 (H×V×D) |
| eneo la bezel(mm) | - |
| matibabu | Hard coating |
| mwangaza | 300 cd/m² (Typ.) |
| uwiano wa utofautishaji | 800 : 1 (Typ.) (TM) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| majibu | 30 (Typ.)(Tr+Td) ms |
| mtazamo mzuri | Symmetry |
| hali ya kazi | - |
| kina cha rangi | 16.7M 50% NTSC |
| backlight | 6S3P WLED , No Driver |
| wingi | 125g (Max.) |
| kutumika kwa | Pad & Tablet |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | On-Cell Touch |
| aina ya ishara | MIPI (4 data lanes) , 39 pins Connector |
| usambazaji wa voltage | 3.3V (Typ.) |
| max. ukadiriaji | Storage Temp.: -20 ~ 70 °C Operating Temp.: -20 ~ 60 °C |
| A070FW03 V7 | AUO | 7.0 | 480×234 |
| AT070TN92 | Innolux | 7.0 | 800×480 |
| AT070TN92 V.1 TP | Innolux | 7.0 | 800×480 |
| CLAA070LF06CW | CPT | 7.0 | 800×480 |
| HJ070NA-13A | Innolux | 7.0 | 1024×600 |
| LA070WV5-SL01 | LG Display | 7.0 | 800×480 |
| LB070W02-TMJ2 | LG Display | 7.0 | 480×234 |
| LQ070Y5DG11 | SHARP | 7.0 | 800×480 |
| P070ACB-DB1 | Innolux | 7.0 | 600×1024 |
| TPF0702002N | JDI | 7.0 | 1200×1920 |
