| Nambari ya Sehemu | TV080WXM-LL3 |
| Chapa | BOE |
| Ukubwa | 8.0 |
| Maombi | Pad & Tablet |
| Azimio | 800×1280 |
| Muundo | a-Si TFT-LCD, Assemb |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | MIPI |
| chapa | BOE |
| mfano | TV080WXM-LL3 |
| ukubwa wa diagonal | 8.0 inch |
| aina | a-Si TFT-LCD, Assembly |
| muundo wa pixel | 800(RGB)×1280 [WXGA] 188PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 107.64(H)×172.224(V) mm |
| muhtasari dim. | 116.9(H)×194.17(V) ×5.35(D) mm |
| eneo la bezel | - |
| matibabu | Clear, Hard coating |
| mwangaza | 350 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000:1 (Typ.) (TM) |
| tazama mwelekeo | Symmetry |
| wakati wa majibu | 30(Typ.)(Tr+Td) |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10) |
| hali ya uendeshaji | ADS, Normally Black, Transmissive |
| rangi ya msaada | 16.7M 60% NTSC |
| chanzo cha mwanga | WLED [5S4P] , W/O Driver |
| uzito | 150g (Typ.) |
| iliyoundwa kwa ajili ya | Pad & Tablet |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | PCAP |
| aina ya kiolesura | MIPI (4 data lanes) , 45 pins Connector |
| usambazaji wa nguvu | 1.8/6.0/-6.0/19/-11V (Typ.)(VDDI/AVDD/AVEE/VGH/VGL) |
| mazingira | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
