| Nambari ya Sehemu | TX09D40VM3CBA |
| Chapa | KOE |
| Ukubwa | 3.5 |
| Maombi | HHP |
| Azimio | 240×320 |
| Muundo | LCM |
| Mwangaza | 430 |
| CR | 300:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | TTL |
| chapa ya paneli | HITACHI |
| mfano wa paneli | TX09D40VM3CBA |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 3.5 inch |
| azimio | 240(RGB)×320 , QVGA |
| hali ya kuonyesha | TN, Normally White, TMR |
| eneo la kazi | 53.64×71.52 mm |
| muhtasari | 64×86×4.5 mm |
| uso | |
| mwangaza | 430 cd/m² (Typ.) |
| uwiano wa utofautishaji | 300 : 1 (Typ.) |
| kuonyesha rangi | 262K (6-bit) |
| wakati wa majibu | 30 (Typ.)(Tr+Td) |
| angle ya kutazama | 80/50/80/80 (Typ.)(CR≥5)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 3S2PWLEDWithout Driver |
| kiolesura cha ishara | Parallel RGB (1 ch, 6-bit), 50 pins |
| voltage ya pembejeo | 3.0/8.45/16.5/-8.05V (Typ.)(VCC/VDH/VGH/VGL) |
| maombi | HHP |
