| Nambari ya Sehemu | NL2432HC22-50B |
| Chapa | NLT |
| Ukubwa | 3.5 |
| Maombi | PDA |
| Azimio | 240×320 |
| Muundo | LCM |
| Mwangaza | 200 |
| CR | 150:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | TTL |
| chapa ya paneli | NEC |
| mfano wa paneli | NL2432HC22-50B |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 3.5 inch |
| azimio | 240(RGB)×320 , QVGA |
| hali ya kuonyesha | TN, Normally White, Transflective |
| eneo la kazi | 53.64×71.52 mm |
| muhtasari | 63.5×84.2 mm |
| uso | Clear, Hard coating (3H) |
| mwangaza | 200 cd/m² (Typ.) |
| uwiano wa utofautishaji | 150:1 (Typ.)(Transmissive)15:1 (Typ.)(Reflective) |
| kuonyesha rangi | 262K (6-bit), CIE193140% |
| wakati wa majibu | 7/23 (Typ.)(Tr/Td) |
| angle ya kutazama | 35/35/35/35 (Typ.)(CR＞5)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | WLEDWithout Driver |
| kiolesura cha ishara | Parallel RGB (1 ch, 6-bit) + SPI, 45 pins |
| voltage ya pembejeo | 3.0V (Typ.) |
| maombi | PDA |
| NL2432HC22-22B | NLT | 3.5 | 240×320 |
| NL2432HC22-23B | NLT | 3.5 | 240×320 |
| NL2432HC22-25E | NLT | 3.5 | 240×320 |
| NL2432HC22-32B | NLT | 3.5 | 240×320 |
| NL2432HC22-40J | NLT | 3.5 | 240×320 |
| NL2432HC22-41B | NLT | 3.5 | 240×320 |
| NL2432HC22-41K | NLT | 3.5 | 240×320 |
| NL2432HC22-50B | NLT | 3.5 | 240×320 |
| PD035VX9 | E Ink | 3.5 | 480×640 |
| TX09D83VM3CEA | KOE | 3.5 | 240×320 |
| LQ035Q7DH02 | SHARP | 3.5 | 240×320 |
| LTM035A776B | TOSHIBA | 3.5 | 240×320 |
| NL2432DR22-02B | NLT | 3.5 | 240×320 |
| NL2432DR22-11B | NLT | 3.5 | 240×320 |
| NL2432HC22-22B | NLT | 3.5 | 240×320 |
| NL2432HC22-41K | NLT | 3.5 | 240×320 |
| NL2432HC22-50B | NLT | 3.5 | 240×320 |
| NL4864HL11-01B | NLT | 3.5 | 480×640 |
| TD035STED7 | TPO | 3.5 | 240×320 |
| TX09D23VM1CAA | KOE | 3.5 | 240×320 |
