| Nambari ya Sehemu | TX20D33VM2BAC |
| Chapa | KOE |
| Ukubwa | 8.0 |
| Maombi | Industrial |
| Azimio | 800×480 |
| Muundo | LCM , a-Si TFT-LCD |
| Mwangaza | |
| CR | 600:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | CMOS |
| mtengenezaji | KOE |
| ukubwa wa skrini | 8.0 inch |
| nambari ya pixel | 800(RGB)×480 (WVGA) 116PPI |
| eneo amilifu(mm) | 174 × 104.4 (H×V) |
| eneo la bezel(mm) | 187.0 × 108.4 (H×V) |
| mwangaza | - |
| angle ya kutazama | 80/80/60/80 (Typ.)(CR≥10) |
| mtazamo mzuri | 6 o'clock |
| kina cha rangi | 262K |
| wingi | 160g |
| kiwango cha upya | 60Hz |
| aina ya ishara | CMOS (1 ch, 6-bit) , 40 pins Connector |
| usambazaji wa voltage | 3.3V (Typ.) |
| max. ukadiriaji | Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| jina la mfano | TX20D33VM2BAC |
| aina ya skrini | LCM , a-Si TFT-LCD |
| mpangilio | RGB Vertical Stripe |
| muhtasari(mm) | 189 × 120 × 8 (H×V×D) |
| matibabu | - |
| uwiano wa utofautishaji | 600 : 1 (Typ.) (TM) |
| majibu | 20 (Typ.)(Tr+Td) ms |
| hali ya kazi | TN, Normally White, Transmissive |
| backlight | WLED , 50K hours , No Driver |
| kutumika kwa | Industrial |
| skrini ya kugusa | Without |
| A080SN01 V8 | AUO | 8.0 | 800×600 |
| AT080TN03 V.1 | Innolux | 8.0 | 800×480 |
| CLAA080LG01CW | CPT | 8.0 | 800×480 |
| HJ080IA-01B | Innolux | 8.0 | 1024×768 |
| LA080WV2-TD01 | LG Display | 8.0 | 800×480 |
| LD080WX2-SMN1 | LG Display | 8.0 | 800×1280 |
| LQ080Y5CGQ1 | SHARP | 8.0 | 800×480 |
| LQ080Y5DZ30A | SHARP | 8.0 | 800×480 |
| N080ICE-GB0 Rev.A1 | Innolux | 8.0 | 800×1280 |
| TM080SV-22L03 | SANYO | 8.0 | 800×600 |
