N080ICE-GB0 Rev.A1

N080ICE-GB0 Rev.A1
N080ICE-GB0 Rev.A1
N080ICE-GB0 Rev.A1 thumb N080ICE-GB0 Rev.A1 thumb
Chapa
Innolux
Ukubwa
8.0
Maombi
PAD
Azimio
800×1280
Muundo
LCM
Mwangaza
400
CR
800:1
Rangi
16.7M
Mwangaza nyuma
WLED
Kiolesura
MIPI
In Stock
1720
Vipimo

Nambari ya Sehemu N080ICE-GB0 Rev.A1
ChapaInnolux
Ukubwa8.0
MaombiPAD
Azimio800×1280
MuundoLCM
Mwangaza400
CR800:1
Rangi16.7M
Mwangaza nyumaWLED
KiolesuraMIPI
chapa ya paneliINNOLUX
mfano wa paneliN080ICE-GB0 Rev.A1
aina ya paneli a-Si TFT-LCD , LCM
saizi ya paneli8.0 inch
azimio800(RGB)×1280 , WXGA
hali ya kuonyeshaAAS, Normally Black, Transmissive
eneo la kazi107.64×172.224 mm
muhtasari114.58×184.09×4.06 mm
usoHard coating, Antireflection
mwangaza400 cd/m² (Typ.)
uwiano wa utofautishaji800:1 (Typ.)
kuonyesha rangi16.7M (8-bit), CIE193160%
wakati wa majibu20 (Typ.)(Tr+Td)
angle ya kutazama89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
masafa60Hz
aina ya taa4 stringsWLEDWithout Driver
kiolesura cha isharaMIPI (4 data lanes), 31 pins
voltage ya pembejeo1.8/3.3V (Typ.)(VDDI/VCI)
maombiPAD
Mfano wa Familia
A080SN03 V2 AUO 8.0 800×600
CLAA080NA01 CW CPT 8.0 1024×600
HJ080IA-01B Innolux 8.0 1024×768
N080ICE-GB0 Rev.A0 Innolux 8.0 800×1280
N080ICE-GB0 Rev.A1 Innolux 8.0 800×1280
N080ICE-GB0 Rev.B1 Innolux 8.0 800×1280
N080ICE-GB0 Rev.C1 Innolux 8.0 800×1280
N080ICE-GB0 Rev.C2 Innolux 8.0 800×1280
N080ICE-GB1 Innolux 8.0 800×1280
TX20D28VM2BAB KOE 8.0 800×480
