| Nambari ya Sehemu | TX26D207VM0AAA |
| Chapa | KOE |
| Ukubwa | 10.1 |
| Maombi | Industrial Outdoor H |
| Azimio | 1280×800 |
| Muundo | a-Si TFT-LCD , LCM |
| Mwangaza | |
| CR | 1500:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa | KOE |
| ukubwa wa diagonal | 10.1 inch |
| muundo wa pixel | 1280(RGB)×800 [WXGA] 149PPI |
| eneo la kazi | 217.344(H)×135.84(V) mm |
| eneo la bezel | 220.344(H)×138.838(V) mm |
| mwangaza | 1000 cd/m² (Typ.) |
| tazama mwelekeo | Symmetry |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| rangi ya msaada | 16.7M 65% NTSC |
| uzito | 340g (Typ.) |
| kiwango cha fremu | 60Hz |
| aina ya kiolesura | LVDS (1 ch, 8-bit) , 20 pins Connector |
| usambazaji wa nguvu | 3.3V (Typ.) |
| mazingira | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 5.0G (49.0 m/s²) |
| mfano | TX26D207VM0AAA |
| aina | a-Si TFT-LCD , LCM |
| usanidi | RGB Vertical Stripe |
| muhtasari dim. | 231(H)×153.5(V) ×11.07(D) mm |
| matibabu | - |
| uwiano wa utofautishaji | 1500:1 (Typ.) (TM) |
| wakati wa majibu | 25 (Max.)(Tr+Tf) |
| hali ya uendeshaji | IPS, Normally Black, Transmissive |
| chanzo cha mwanga | WLED , 70K hours , With LED Driver |
| iliyoundwa kwa ajili ya | Industrial Outdoor High Brightness Automotive Display |
| jopo la kugusa | Without |
| AM-19201200B1TZQW-T00 | AMPIRE | 10.1 | 1920×1200 |
| HSD100IFW1-F03 | HannStar | 10.1 | 1024×600 |
| HSD101PWW1-G10 | HannStar | 10.1 | 1280×800 |
| LP101WH1-TLB1 | LG Display | 10.1 | 1366×768 |
| LP101WH1-TLB2 | LG Display | 10.1 | 1366×768 |
| LP101WX1-SLP2 | LG Display | 10.1 | 1280×800 |
| LTN101NT02-B01 | Samsung | 10.1 | 1024×600 |
| N101ICG-L21 Rev.B1 | Innolux | 10.1 | 1280×800 |
| TX26D202VM0BAA | KOE | 10.1 | 1920×1200 |
| TX26D203VM2BAA | KOE | 10.4 | 1024×768 |
