| Nambari ya Sehemu | WEO009616AW |
| Chapa | Winstar |
| Ukubwa | 0.84 |
| Maombi | Wearable |
| Azimio | 96×16 |
| Muundo | PM-OLED , OLED |
| Mwangaza | |
| CR | |
| Rangi | Mono(White) |
| Mwangaza nyuma | self |
| Kiolesura | I²C |
| chapa | Winstar |
| ukubwa wa diagonal | 0.84 inch |
| muundo wa pixel | 96×16 115PPI |
| eneo la kazi | 21.104(H)×3.504(V) mm |
| eneo la bezel | 23.104(H)×5.504(V) mm |
| tazama mwelekeo | Symmetry |
| angle ya kutazama | - |
| rangi ya msaada | Mono(White) |
| uzito | - |
| kiwango cha fremu | - |
| maelezo ya d-ic | COG Built-in SSD1306BZ |
| aina ya kiolesura | I²C , 14 pins FPC |
| usambazaji wa nguvu | 3.0V (Typ.) |
| mazingira | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 85 °C |
| mfano | WEO009616AW |
| aina | PM-OLED , OLED |
| usanidi | Rectangle |
| muhtasari dim. | 29.1(H)×9.2(V) ×1.46(D) mm |
| matibabu | - |
| wakati wa majibu | - |
| hali ya uendeshaji | - |
| chanzo cha mwanga | self |
| iliyoundwa kwa ajili ya | Wearable |
| jopo la kugusa | Without |
| UG-9616TLBBG01 | WiseChip | 0.84 | 96×16 |
| UG-9616TSWBG01 | WiseChip | 0.84 | 96×16 |
