| Nambari ya Sehemu | WF57STIACDNG0 |
| Chapa | Winstar |
| Ukubwa | 5.7 |
| Maombi | Industrial |
| Azimio | 320×240 |
| Muundo | a-Si TFT-LCD , LCM |
| Mwangaza | |
| CR | 800:1 |
| Rangi | Grayscale |
| Mwangaza nyuma | WLED |
| Kiolesura | 8/16-bit |
| chapa | Winstar |
| ukubwa wa diagonal | 5.7 inch |
| muundo wa pixel | 320×240 [QVGA] 70PPI |
| eneo la kazi | 115.2(H)×86.4(V) mm |
| eneo la bezel | 117.9(H)×89.1(V) mm |
| mwangaza | 800 cd/m² (Typ.) |
| tazama mwelekeo | 12 o'clock |
| angle ya kutazama | - |
| rangi ya msaada | Grayscale |
| uzito | - |
| kiwango cha fremu | - |
| aina ya kiolesura | 8/16-bit 6800/8080 parallel, 3/4-wire SPI , 22 pins FPC |
| usambazaji wa nguvu | 3.3V (Typ.) |
| mazingira | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| mfano | WF57STIACDNG0 |
| aina | a-Si TFT-LCD , LCM |
| usanidi | Rectangle |
| muhtasari dim. | 160(H)×109(V) ×9.24(D) mm |
| matibabu | Glare (Haze 0%) |
| uwiano wa utofautishaji | 800:1 (Typ.) (TM) |
| wakati wa majibu | - |
| hali ya uendeshaji | TN, Normally White, Transmissive |
| chanzo cha mwanga | WLED , W/O Driver |
| iliyoundwa kwa ajili ya | Industrial |
| jopo la kugusa | PCAP |
