| Nambari ya Sehemu | YX035CM31 |
| Chapa | |
| Ukubwa | 3.5 |
| Maombi | HHP |
| Azimio | 320×240 |
| Muundo | LCM |
| Mwangaza | 800 |
| CR | 400:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | Parallel/Serial |
| chapa ya paneli | |
| mfano wa paneli | YX035CM31 1 Compatible model |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 3.5 inch |
| azimio | 320(RGB)×240 , QVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 70.08×52.56 mm |
| muhtasari | 76.9×63.9 mm |
| uso | Antiglare (Haze 20%) |
| mwangaza | 800 cd/m² (Typ.) |
| uwiano wa utofautishaji | 400:1 (Typ.) |
| kuonyesha rangi | 16.7M (8-bit) |
| wakati wa majibu | 10/15 (Typ.)(Tr/Td) |
| angle ya kutazama | 60/60/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 5S2PWLEDWithout Driver |
| kiolesura cha ishara | Digital RGB (8/24-bit) + SPI, CCIR601/656, 54 pins |
| voltage ya pembejeo | 3.3/13.9/13.6V (Typ.)(VCC/VGH/VGL) |
| maombi | HHP |
