A030DN01 V0

A030DN01 V0
A030DN01 V0
A030DN01 V0 thumb A030DN01 V0 thumb
Chapa
AUO
Ukubwa
3.0
Maombi
DSC
Azimio
320×240
Muundo
LCM
Mwangaza
250
CR
300:1
Rangi
16.7M
Mwangaza nyuma
WLED
Kiolesura
Serial RGB
In Stock
13647
Vipimo

Nambari ya Sehemu A030DN01 V0
ChapaAUO
Ukubwa3.0
MaombiDSC
Azimio320×240
MuundoLCM
Mwangaza250
CR300:1
Rangi16.7M
Mwangaza nyumaWLED
KiolesuraSerial RGB
chapa ya paneliAUO
mfano wa paneliA030DN01 V0
aina ya paneli a-Si TFT-LCD , LCM
saizi ya paneli3.0 inch
azimio320(RGB)×240 , QVGA
hali ya kuonyeshaTN, Normally White, Transmissive
eneo la kazi60×45 mm
muhtasari70.2×51.4 mm
usoHard coating
mwangaza250 cd/m² (Typ.)
uwiano wa utofautishaji300:1 (Typ.)
kuonyesha rangi16.7M (8-bit)
wakati wa majibu15/20 (Typ.)(Tr/Td)
angle ya kutazama55/55/45/60 (Typ.)(CR≥10)(L/R/U/D)
masafa60Hz
aina ya taa2S1PWLEDWithout Driver
kiolesura cha isharaSerial RGB (8-bit) + SPI, CCIR601/656, 40 pins
voltage ya pembejeo3.3/3.3V (Typ.)(VDD/VDDIO)
maombiDSC
Mfano wa Familia
990000881 TPO 3.0 960×480(dot)
A030DN01 V0 AUO 3.0 320×240
A030DN01 V9 AUO 3.0 320×240
A030DN01 VC AUO 3.0 320×240
A030DN04 V0 AUO 3.0 320×240
A030DN05 V0 AUO 3.0 320×240
A030DW01 V0 AUO 3.0 320×240
A030DW01 V1 AUO 3.0 320×240
A030DW01 V3 AUO 3.0 320×240
DX08D11VM0AAA KOE 3.0 480×800
