| Nambari ya Sehemu | A030DW01 V3 |
| Chapa | AUO |
| Ukubwa | 3.0 |
| Maombi | DSC |
| Azimio | 320×240 |
| Muundo | LCM |
| Mwangaza | 350 |
| CR | 300:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | Serial RGB |
| chapa ya paneli | AUO |
| mfano wa paneli | A030DW01 V3 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 3.0 inch |
| azimio | 320(RGB)×240 , QVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 65.52×36.84 mm |
| muhtasari | 74.92×42.74 mm |
| uso | Hard coating |
| mwangaza | 350 cd/m² (Typ.) |
| uwiano wa utofautishaji | 300:1 (Typ.) |
| kuonyesha rangi | 16.7M (8-bit) |
| wakati wa majibu | 15/20 (Typ.)(Tr/Td) |
| angle ya kutazama | 60/60/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| aina ya taa | 3S1PWLEDWithout Driver |
| kiolesura cha ishara | Serial RGB (8-bit) + SPI, CCIR601/656, 39 pins |
| voltage ya pembejeo | 3.3/15/-10V (Typ.)(VDD/VGH/VGL) |
| maombi | DSC |
| A030DN01 V0 | AUO | 3.0 | 320×240 |
| A030DN01 V9 | AUO | 3.0 | 320×240 |
| A030DN01 VC | AUO | 3.0 | 320×240 |
| A030DN04 V0 | AUO | 3.0 | 320×240 |
| A030DN05 V0 | AUO | 3.0 | 320×240 |
| A030DW01 V0 | AUO | 3.0 | 320×240 |
| A030DW01 V1 | AUO | 3.0 | 320×240 |
| A030DW01 V3 | AUO | 3.0 | 320×240 |
| COM30T3N64ZLG | ORTUSTECH | 3.0 | 320×240 |
| TFTMD030035 | JDI | 3.0 | 640×480 |
| 990000881 | TPO | 3.0 | 960×480(dot) |
| A030DN01 VC | AUO | 3.0 | 320×240 |
| A030JTN01.1 | AUO | 3.0 | 960×480(dot) |
| FX020410DNSWBG01 | Data Image | 2.4 | 480×234 |
| LQ027A3DA01 | SHARP | 2.7 | 320×240 |
| LQ035JC211 | Innolux | 3.5 | 320×240 |
| LQ035LC111 | Innolux | 3.5 | 320×240 |
| PA025XSB | E Ink | 2.5 | 480×234 |
| PA035XSL | E Ink | 3.5 | 320×234 |
| TM027CDH04 | Tianma | 2.7 | 320×240 |
