| Nambari ya Sehemu | A070XN01 V0 |
| Chapa | AUO |
| Ukubwa | 7.0 |
| Maombi | |
| Azimio | 1024×768 |
| Muundo | LCM |
| Mwangaza | 330 |
| CR | 800:1 |
| Rangi | 16.2M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | AUO |
| mfano wa paneli | A070XN01 V0 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 7.0 inch |
| azimio | 1024(RGB)×768 , XGA |
| hali ya kuonyesha | MVA, Normally Black, Transmissive |
| eneo la kazi | 141.312×105.984 mm |
| muhtasari | 154×119.2×3.5 mm |
| uso | Antiglare, Hard coating (3H) |
| mwangaza | 330 cd/m² (Typ.) |
| uwiano wa utofautishaji | 800:1 (Typ.) |
| kuonyesha rangi | 16.2M (6-bit + FRC), CIE193145% |
| wakati wa majibu | 15/10 (Typ.)(Tr/Td) |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 3S9PWLEDWithout Driver |
| kiolesura cha ishara | LVDS (1 ch, 8-bit), 40 pins |
| voltage ya pembejeo | 3.3/5/-5V (Typ.)(VDDIO/VDPA/VDNA) |
