| Nambari ya Sehemu | A080SN03 V2 |
| Chapa | AUO |
| Ukubwa | 8.0 |
| Maombi | DPF |
| Azimio | 800×600 |
| Muundo | CELL |
| Mwangaza | 0 |
| CR | 500:1 |
| Rangi | 16.2M |
| Mwangaza nyuma | No B/L |
| Kiolesura | TTL |
| chapa ya paneli | AUO |
| mfano wa paneli | A080SN03 V2 |
| aina ya paneli | a-Si TFT-LCD , CELL |
| saizi ya paneli | 8.0 inch |
| azimio | 800×600(RGB) , SVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 162×121.5 mm |
| muhtasari | 170.1×132.3 mm |
| uso | Antiglare, Hard coating (3H) |
| kioo kina | 0.50+0.50 mm |
| uhamishaji | 4.88% (Typ.)(with Polarizer) |
| uwiano wa utofautishaji | 500:1 (Typ.) |
| kuonyesha rangi | 16.2M (6-bit + Dithering), CIE193150% |
| wakati wa majibu | 12/18 (Typ.)(Tr/Td) |
| angle ya kutazama | 70/70/60/65 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| kiolesura cha ishara | TTL (1 ch, 8-bit) + SPI, 60 pins |
| voltage ya pembejeo | 3.3/5/-5/14/-14V (Typ.)(VDDIO/VDPA/VDNA/VGH/VGL) |
| maombi | DPF |
