Innolux LW700AT9309 hifadhidata, vipimo, hisa, programu www.looklcd-mk.com

LW700AT9309


Chapa
Innolux
Ukubwa
7.0
Maombi
DPF
Azimio
800×480
Muundo
LCM
Mwangaza
350
CR
400:1
Rangi
262K
Mwangaza nyuma
WLED
Kiolesura
TTL
In Stock
11360
Vipimo

Nambari ya Sehemu LW700AT9309
ChapaInnolux
Ukubwa7.0
MaombiDPF
Azimio800×480
MuundoLCM
Mwangaza350
CR400:1
Rangi262K
Mwangaza nyumaWLED
KiolesuraTTL
chapa ya paneliChiHsin
mfano wa paneliLW700AT9309 1 Compatible model
aina ya paneli a-Si TFT-LCD , LCM
saizi ya paneli7.0 inch
azimio800(RGB)×480 , WVGA
hali ya kuonyeshaTN, Normally White, Transmissive
eneo la kazi152.4×91.44 mm
muhtasari165×104.44×5.9 mm
usoAntiglare
mwangaza350 cd/m² (Typ.)
uwiano wa utofautishaji400:1 (Typ.)
kuonyesha rangi262K (6-bit), CIE193145%
wakati wa majibu5/11 (Typ.)(Tr/Td)
angle ya kutazama70/70/60/70 (Typ.)(CR≥10)(L/R/U/D)
masafa60Hz
aina ya taa3S8PWLEDWithout Driver
kiolesura cha isharaTTL (1 ch, 6-bit), 40 pins
voltage ya pembejeo3.3V (Typ.)
maombiDPF
Mfano wa Familia
AT070TN83 V.1 Innolux 7.0 800×480
BP070WX1-100 BOE 7.0 1280×800
CLAA070LFB1 CW CPT 7.0 800×480
DLC0700FDG-T-6 Other 7.0 800×480
LT070ME05000 JDI 7.0 1200×1920
LW700AT9003 Innolux 7.0 800×480
LW700AT9008 Innolux 7.0 800×480
LW700AT9009 Innolux 7.0 800×480
LW700AT9309 Innolux 7.0 800×480
LW700AT9901 Innolux 7.0 800×480
