| Nambari ya Sehemu | AA090AA01 |
| Chapa | Mitsubishi |
| Ukubwa | 9.0 |
| Maombi | IA |
| Azimio | 960×540 |
| Muundo | LCM |
| Mwangaza | 400 |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | Mitsubishi |
| mfano wa paneli | AA090AA01 1 Compatible model |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 9.0 inch |
| azimio | 960(RGB)×540 , qHD |
| hali ya kuonyesha | IPS, Normally Black, Transmissive |
| eneo la kazi | 198.72×111.78 mm |
| muhtasari | 217×130 mm |
| uso | Antiglare, Hard coating (3H) |
| mwangaza | 400 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000:1 (Typ.) |
| kuonyesha rangi | 16.7M (8-bit), CIE193172% |
| wakati wa majibu | 8/8 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | WLEDEmbedded (LED Driver) |
| kiolesura cha ishara | LVDS (1 ch, 8-bit), 20 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | IA |
