| Nambari ya Sehemu | T-55561D090J-LW-A-AAN |
| Chapa | Kyocera |
| Ukubwa | 9.0 |
| Maombi | IA |
| Azimio | 800×480 |
| Muundo | LCM |
| Mwangaza | 400 |
| CR | 900:1 |
| Rangi | 262K/16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | OPTREX |
| mfano wa paneli | T-55561D090J-LW-A-AAN 1 Compatible model |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 9.0 inch |
| azimio | 800(RGB)×480 , WVGA |
| hali ya kuonyesha | IPS, Normally Black, Transmissive |
| eneo la kazi | 196.8×118.08 mm |
| muhtasari | 219×136.2 mm |
| uso | Antiglare, Hard coating (3H) |
| mwangaza | 400 cd/m² (Typ.) |
| uwiano wa utofautishaji | 900:1 (Typ.) |
| kuonyesha rangi | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193172% |
| wakati wa majibu | 12/12 (Typ.)(Tr/Td) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 7S2PWLEDWithout Driver |
| kiolesura cha ishara | LVDS (1 ch, 6/8-bit), 20 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | IA |
| AA090MC01 | Mitsubishi | 9.0 | 800×480 |
| AA090ME01 | Mitsubishi | 9.0 | 800×480 |
| AT090TN12 V.3 | Innolux | 9.0 | 800×480 |
| C090EAN01.1 | AUO | 9.0 | 1280×720 |
| HSD090IDW1-A00 | HannStar | 9.0 | 800×480 |
| LQ090Y3DG01A | SHARP | 9.0 | 800×480 |
| NL192108AC10-01D | NLT | 9.0 | 1920×1080 |
| T-55561D090J-LW-A-AAN | Kyocera | 9.0 | 800×480 |
| YXD090TN02-40NM01 | SEBO | 9.0 | 1280×800 |
| ZE090NA-01B | Innolux | 9.0 | 1280×800 |
| AA090MC01 | Mitsubishi | 9.0 | 800×480 |
| EDTCB29QB0 | Panasonic | 10.4 | 800×600 |
| EL160.80.50 | Lumineq | 3.5 | 160×80 |
| G6481L-FF | CITIZEN | 10.4 | 640×480 |
| LM057QB1T073 | SHARP | 5.7 | 320×240 |
| LM081HB1T01 | SHARP | 8.1 | 640×240 |
| LM238WR2-SLA1 | LG Display | 23.8 | 3840×2160 |
| LQ104V1DC41 | SHARP | 10.4 | 640×480 |
| LQ9D03B | SHARP | 8.4 | 640×480 |
| OEL9M0065-R-E | Other | 2.7 | 256×64 |
