| Nambari ya Sehemu | LTL090CL01-W02 |
| Chapa | Samsung |
| Ukubwa | 9.0 |
| Maombi | PAD |
| Azimio | 1920×1280 |
| Muundo | LCM |
| Mwangaza | 400 |
| CR | 800:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | MIPI |
| chapa ya paneli | SAMSUNG |
| mfano wa paneli | LTL090CL01-W02 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 9.0 inch |
| azimio | 1920(RGB)×1280 |
| hali ya kuonyesha | PLS, Normally Black, Transmissive |
| eneo la kazi | 190.08×126.72 mm |
| muhtasari | 200.91×141.21×2.728 mm |
| uso | |
| mwangaza | 400 cd/m² (Typ.) |
| uwiano wa utofautishaji | 800:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit), CIE193150% |
| wakati wa majibu | 16 (Typ.)(Tr+Td) |
| angle ya kutazama | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 7S5PWLEDWithout Driver |
| kiolesura cha ishara | MIPI (4 data lanes), 40 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | PAD |
