| Nambari ya Sehemu | AM-1024600ITZQW-T00H |
| Chapa | AMPIRE |
| Ukubwa | 10.1 |
| Maombi | Industrial |
| Azimio | 1024×600 |
| Muundo | LCM , a-Si TFT-LCD |
| Mwangaza | |
| CR | 500:1 |
| Rangi | 262K/16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| mtengenezaji | AMPIRE |
| ukubwa wa skrini | 10.1 inch |
| nambari ya pixel | 1024(RGB)×600 (WSVGA) 117PPI |
| eneo amilifu(mm) | 222.72 × 125.28 (H×V) |
| eneo la bezel(mm) | - |
| mwangaza | 465 cd/m² (Typ.) |
| angle ya kutazama | 89/89/89/89 (Typ.)(CR≥10) |
| mtazamo mzuri | Symmetry |
| kina cha rangi | 262K/16.7M 70% NTSC |
| wingi | - |
| kiwango cha upya | 60Hz |
| aina ya ishara | LVDS (1 ch, 6/8-bit) , 40 pins Connector |
| usambazaji wa voltage | 3.3/12.5/20/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| max. ukadiriaji | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| jina la mfano | AM-1024600ITZQW-T00H |
| aina ya skrini | LCM , a-Si TFT-LCD |
| mpangilio | RGB Vertical Stripe |
| muhtasari(mm) | 255 × 165.8 (H×V×D) |
| matibabu | Antiglare, Hard coating |
| uwiano wa utofautishaji | 500 : 1 (Typ.) (TM) |
| majibu | 12/28 (Typ.)(Tr/Td) ms |
| hali ya kazi | IPS, Normally Black, Transmissive |
| backlight | WLED , 50K hours , No Driver |
| kutumika kwa | Industrial |
| skrini ya kugusa | PCAP |
| AM-1024600-070H | Other | 7.0 | 1024×600 |
| AM-1024600KTMQW-01H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600KTMQW-04H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600L3TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| AM-1024600L7TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| CLAA101NC01CW | CPT | 10.1 | 1024×600 |
| LTN101AL01-F01 | Samsung | 10.1 | 1280×800 |
| LTN101AL03-801 | Samsung | 10.1 | 1280×800 |
| TM101DDHG03 | Tianma | 10.1 | 1024×600 |
| VVX10F002A00 | Panasonic | 10.1 | 1920×1200 |
