| Nambari ya Sehemu | TM101DDHG03 |
| Chapa | Tianma |
| Ukubwa | 10.1 |
| Maombi | IA |
| Azimio | 1024×600 |
| Muundo | LCM |
| Mwangaza | 300 |
| CR | 800:1 |
| Rangi | 262K/16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | TIANMA |
| mfano wa paneli | TM101DDHG03 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 10.1 inch |
| azimio | 1024(RGB)×600 , WSVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 222.72×125.28 mm |
| muhtasari | 233×137×3.2 mm |
| uso | Antiglare, Hard coating (3H) |
| mwangaza | 300 cd/m² (Typ.) |
| uwiano wa utofautishaji | 800:1 (Typ.) |
| kuonyesha rangi | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193150% |
| wakati wa majibu | 7/9 (Typ.)(Tr/Td) |
| angle ya kutazama | 80/80/75/80 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 3S10PWLEDEmbedded (LED Driver) |
| kiolesura cha ishara | LVDS (1 ch, 6/8-bit), 41 pins |
| voltage ya pembejeo | 3.3/11.02/21.14/-7V (Typ.)(VDD/AVDD/VGH/VGL) |
| maombi | IA |
| AT101WSM-NW0-3800(3900) | BOE | 10.1 | 1024×600 |
| BP101WX1-100 | BOE | 10.1 | 1280×800 |
| HSD101PFW2-C00 | HannStar | 10.1 | 1024×600 |
| HSD101PWW1-H00 | HannStar | 10.1 | 1280×800 |
| LP101WS1-TLA1 | LG Display | 10.1 | 1024×576 |
| LP101WSB-TLN1 | LG Display | 10.1 | 1024×600 |
| N101N6-L02 | Innolux | 10.1 | 1024×576 |
| TM101DDHG01 | Tianma | 10.1 | 1024×600 |
| TM101DDHG03 | Tianma | 10.1 | 1024×600 |
| TM101JDHP01 | Tianma | 10.1 | 1280×800 |
| DLC1210BBG | Other | 12.1 | 800×600 |
| EG4401S-FR-1 | Epson | 5.3 | 256×128 |
| G101EVN01.0 | AUO | 10.1 | 1280×800 |
| G150XGE-L06 | Innolux | 15.0 | 1024×768 |
| LQ084V1DG22 | SHARP | 8.4 | 640×480 |
| LTA104D182F | TOSHIBA | 10.4 | 800×600 |
| RGS24128064YW005 | RiTdisplay | 2.4 | 128×64 |
| SX19V001-Z2A | KOE | 7.5 | 640×480 |
| TM057KDHG03 | Tianma | 5.7 | 320×240 |
| UG-9696TDDCG02 | WiseChip | 1.1 | 96×96 |
