| Nambari ya Sehemu | AM-1024600K5TMQW-T00H |
| Chapa | AMPIRE |
| Ukubwa | 7.0 |
| Maombi | Industrial |
| Azimio | 1024×600 |
| Muundo | LCM, a-Si TFT-LCD |
| Mwangaza | |
| CR | 700:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 5S3P |
| Kiolesura | LVDS |
| mtengenezaji | AMPIRE |
| jina la mfano | AM-1024600K5TMQW-T00H |
| ukubwa wa skrini | 7.0 inch |
| aina ya skrini | LCM, a-Si TFT-LCD |
| nambari ya pixel | 1024(RGB)×600 (WSVGA) 169PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 153.6 × 90 (H×V) |
| muhtasari(mm) | 165.5 × 103 × 11.02 (H×V×D) |
| mwangaza | 400 cd/m² (Typ.) |
| uwiano wa utofautishaji | 700 : 1 (Typ.) (TM) |
| angle ya kutazama | 75/75/70/75 (Typ.)(CR≥10) |
| majibu | 20/20 (Typ.)(Tr/Td) ms |
| mtazamo mzuri | - |
| hali ya kazi | TN, Normally White, Transmissive |
| kina cha rangi | 16.7M |
| backlight | 5S3P WLED , 30K hours , With LED Driver |
| wingi | TBD |
| kutumika kwa | Industrial |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | 4-wire Resistive Touch |
| aina ya ishara | LVDS (1 ch, 8-bit) , Connector 20 pins |
| usambazaji wa voltage | 3.3V (Typ.) |
| max. ukadiriaji | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
