| Nambari ya Sehemu | AM-1024600K7TMQW-T19H |
| Chapa | AMPIRE |
| Ukubwa | 7.0 |
| Maombi | Industrial |
| Azimio | 1024×600 |
| Muundo | a-Si TFT-LCD , LCM |
| Mwangaza | |
| CR | 700:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | |
| chapa | AMPIRE |
| ukubwa wa diagonal | 7.0 inch |
| muundo wa pixel | 1024(RGB)×600 [WSVGA] 169PPI |
| eneo la kazi | 153.6(H)×90(V) mm |
| mwangaza | 425 cd/m² (Typ.) |
| tazama mwelekeo | 6 o'clock |
| angle ya kutazama | 75/75/70/75 (Typ.)(CR≥10) |
| rangi ya msaada | 16.7M |
| uzito | TBD |
| kiwango cha fremu | 60Hz |
| mfano | AM-1024600K7TMQW-T19H |
| aina | a-Si TFT-LCD , LCM |
| usanidi | RGB Vertical Stripe |
| muhtasari dim. | 165.5(H)×104.44(V) ×10.81(D) mm |
| uwiano wa utofautishaji | 700:1 (Typ.) (TM) |
| wakati wa majibu | 20/20 (Typ.)(Tr/Td) |
| hali ya uendeshaji | TN, Normally White, Transmissive |
| chanzo cha mwanga | WLED [5S3P] , 30K hours , With LED Driver |
| iliyoundwa kwa ajili ya | Industrial |
| jopo la kugusa | PCAP |
| 70WVW1A | SII | 7.0 | 800×480 |
| 70WVW1T | SII | 7.0 | 800×480 |
| A070VW08 V0 | AUO | 7.0 | 800×480 |
| A070XN01 V0 | AUO | 7.0 | 1024×768 |
| AM-1024600-070H | Other | 7.0 | 1024×600 |
| AM-1024600KTMQW-01H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600KTMQW-04H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600L3TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| AM-1024600L7TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| AT070TN92 V.3 | Innolux | 7.0 | 800×480 |
