| Nambari ya Sehemu | AM-1024600L2HMQW-T01H |
| Chapa | AMPIRE |
| Ukubwa | 10.1 |
| Maombi | Industrial |
| Azimio | 1024×600 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 500:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa | AMPIRE |
| mfano | AM-1024600L2HMQW-T01H |
| ukubwa wa diagonal | 10.1 inch |
| aina | a-Si TFT-LCD, LCM |
| muundo wa pixel | 1024(RGB)×600 [WSVGA] 117PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 222.72(H)×125.28(V) mm |
| muhtasari dim. | 235(H)×145.8(V) ×9.8(D) mm |
| eneo la bezel | 225.92(H)×128.48(V) mm |
| matibabu | - |
| mwangaza | 800 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500:1 (Typ.) (TM) |
| tazama mwelekeo | - |
| wakati wa majibu | 4/12 (Typ.)(Tr/Td) |
| angle ya kutazama | 70/70/70/50 (Typ.)(CR≥10) |
| hali ya uendeshaji | TN, Normally White, Transmissive |
| rangi ya msaada | 262K 47% NTSC |
| chanzo cha mwanga | WLED [6S6P] , 50K hours , With LED Driver |
| uzito | TBD |
| iliyoundwa kwa ajili ya | Industrial |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | 4-wire Resistive Touch |
| aina ya kiolesura | LVDS (1 ch, 6-bit) , 30 pins Connector |
| usambazaji wa nguvu | 3.3V (Typ.) |
| mazingira | Operating Temperature: -5 ~ 60 °C ; Storage Temperature: -20 ~ 70 °C |
