| Nambari ya Sehemu | HSD101PUW1-A00 |
| Chapa | HannStar |
| Ukubwa | 10.1 |
| Maombi | PAD |
| Azimio | 1920×1200 |
| Muundo | LCM |
| Mwangaza | 380 |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | MIPI |
| chapa ya paneli | HannStar |
| mfano wa paneli | HSD101PUW1-A00 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 10.1 inch |
| azimio | 1920(RGB)×1200 , WUXGA |
| hali ya kuonyesha | HS-IPS, Normally Black, Transmissive |
| eneo la kazi | 216.576×135.36 mm |
| muhtasari | 227.72×147.8×4.55 mm |
| uso | Hard coating |
| mwangaza | 380 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000:1 (Typ.) |
| kuonyesha rangi | 16.7M (6-bit + Hi-FRC), CIE193150% |
| wakati wa majibu | 25 (Typ.)(Tr+Td) |
| angle ya kutazama | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | WLEDEmbedded (LED Driver) |
| kiolesura cha ishara | MIPI (4 data lanes), 34 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | PAD |
