| Nambari ya Sehemu | AM-1024768V1TZQW-A0H |
| Chapa | AMPIRE |
| Ukubwa | 8.4 |
| Maombi | Industrial |
| Azimio | 1024×768 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa | AMPIRE |
| mfano | AM-1024768V1TZQW-A0H |
| ukubwa wa diagonal | 8.4 inch |
| aina | a-Si TFT-LCD, LCM |
| muundo wa pixel | 1024(RGB)×768 [XGA] 152PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 170.8(H)×128.1(V) mm |
| muhtasari dim. | 203(H)×145.5(V) ×8(D) mm |
| eneo la bezel | 174.15(H)×131.2(V) mm |
| matibabu | - |
| mwangaza | 1000 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000:1 (Typ.) (TM) |
| tazama mwelekeo | Symmetry |
| wakati wa majibu | 30 (Typ.)(Tr+Td) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| hali ya uendeshaji | IPS, Normally Black, Transmissive |
| rangi ya msaada | 16.7M |
| chanzo cha mwanga | WLED [6S6P] , 50K hours , With LED Driver |
| uzito | - |
| iliyoundwa kwa ajili ya | Industrial |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | Without |
| aina ya kiolesura | LVDS (1 ch, 8-bit) , 20 pins Connector |
| usambazaji wa nguvu | 3.3V (Typ.) |
| mazingira | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 85 °C |
