| Nambari ya Sehemu | AM-800480BDTZQW-00H |
| Chapa | AMPIRE |
| Ukubwa | 4.3 |
| Maombi | Industrial Automotiv |
| Azimio | 800×480 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 700:1 |
| Rangi | 16.2M |
| Mwangaza nyuma | WLED |
| Kiolesura | Parallel |
| chapa | AMPIRE |
| mfano | AM-800480BDTZQW-00H |
| ukubwa wa diagonal | 4.3 inch |
| aina | a-Si TFT-LCD, LCM |
| muundo wa pixel | 800(RGB)×480 [WVGA] 216PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 95.04(H)×53.856(V) mm |
| muhtasari dim. | 105.3(H)×67(V) mm |
| eneo la bezel | 97.9(H)×56.7(V) mm |
| matibabu | - |
| mwangaza | 500 cd/m² (Typ.) |
| uwiano wa utofautishaji | 700:1 (Typ.) (TM) |
| tazama mwelekeo | Symmetry |
| wakati wa majibu | 40 (Typ.)(Tr+Td) |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10) |
| hali ya uendeshaji | Normally Black, Transmissive |
| rangi ya msaada | 16.2M |
| chanzo cha mwanga | WLED [6S2P] , 50K hours , W/O Driver |
| uzito | - |
| iliyoundwa kwa ajili ya | Industrial Automotive Display |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | Without |
| aina ya kiolesura | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| usambazaji wa nguvu | 3.3V (Typ.) |
| mazingira | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C |
