| Nambari ya Sehemu | AM-800480CTZQW-A5H |
| Chapa | AMPIRE |
| Ukubwa | 7.0 |
| Maombi | Industrial Outdoor H |
| Azimio | 800×480 |
| Muundo | LCM , a-Si TFT-LCD |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 262K |
| Mwangaza nyuma | 6S5P |
| Kiolesura | LVDS |
| mtengenezaji | AMPIRE |
| jina la mfano | AM-800480CTZQW-A5H |
| ukubwa wa skrini | 7.0 inch |
| aina ya skrini | LCM , a-Si TFT-LCD |
| nambari ya pixel | 800(RGB)×480 (WVGA) 133PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 152.4 × 91.44 (H×V) |
| muhtasari(mm) | 165 × 104.4 × 11.61 (H×V×D) |
| eneo la bezel(mm) | 15.48 × 93.85 (H×V) |
| matibabu | - |
| mwangaza | 1500 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000 : 1 (Typ.) (TM) |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10) |
| majibu | 25 (Typ.)(Tr+Td) ms |
| mtazamo mzuri | Symmetry |
| hali ya kazi | IPS, Normally Black, Transmissive |
| kina cha rangi | 262K 58% NTSC |
| backlight | 6S5P WLED , 50K hours , With LED Driver |
| wingi | - |
| kutumika kwa | Industrial Outdoor High Brightness |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | Without |
| aina ya ishara | LVDS (1 ch, 6-bit) , 20 pins Connector |
| usambazaji wa voltage | 12.0V (Typ.) |
| max. ukadiriaji | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
