| Nambari ya Sehemu | AM-800480D1TMQW-00H |
| Chapa | AMPIRE |
| Ukubwa | 8.0 |
| Maombi | Industrial Automotiv |
| Azimio | 800×480 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 500:1 |
| Rangi | 262K/16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | |
| chapa | AMPIRE |
| mfano | AM-800480D1TMQW-00H |
| ukubwa wa diagonal | 8.0 inch |
| aina | a-Si TFT-LCD, LCM |
| muundo wa pixel | 800(RGB)×480 [WVGA] 116PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 176.64(H)×99.36(V) mm |
| muhtasari dim. | 192.8(H)×116.9(V) ×6.7(D) mm |
| eneo la bezel | 180.1(H)×103.4(V) mm |
| matibabu | Antiglare |
| mwangaza | 450 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500:1 (Typ.) (TM) |
| tazama mwelekeo | - |
| wakati wa majibu | 10/15 (Typ.)(Tr/Td) |
| angle ya kutazama | 70/70/50/70 (Typ.)(CR≥10) |
| hali ya uendeshaji | TN, Normally White, Transmissive |
| rangi ya msaada | 262K/16.7M |
| chanzo cha mwanga | WLED , 20K hours , W/O Driver |
| uzito | 251g (Typ.) |
| iliyoundwa kwa ajili ya | Industrial Automotive Display |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | Without |
| Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C |
| AM-800480-050D | Other | 5.0 | 800×480 |
| AM-800480LATMQW-TN0H | AMPIRE | 5.0 | 800×480 |
| AM-800480LTMQW-00H-F | AMPIRE | 5.0 | 800×480 |
| AM-800480LTMQW-W0H | AMPIRE | 5.0 | 800×480 |
| AM-800480R3TMQW-B2H | AMPIRE | 7.0 | 800×480 |
| AM-800480RCTMQW-00H | AMPIRE | 7.0 | 800×480 |
| AM-800480RSTMQW-TA1H | AMPIRE | 7.0 | 800×480 |
| AM-800480RWTMQW-TA4H | AMPIRE | 7.0 | 800×480 |
| AM-800480STMQW-00 | AMPIRE | 7.0 | 800×480 |
| AM-800480STMQW-W0 | AMPIRE | 7.0 | 800×480 |
