| Nambari ya Sehemu | AM-800600MTMQW-50H |
| Chapa | AMPIRE |
| Ukubwa | 8.4 |
| Maombi | Industrial Outdoor H |
| Azimio | 800×600 |
| Muundo | a-Si TFT-LCD , LCM |
| Mwangaza | |
| CR | 600:1 |
| Rangi | 262K/16.7M |
| Mwangaza nyuma | 6S5P |
| Kiolesura | |
| chapa ya paneli | AMPIRE |
| saizi ya paneli | 8.4" |
| azimio | 800(RGB)×600, SVGA, 119PPI |
| eneo la maonyesho | 170.4(W)×127.8(H) mm |
| saizi ya muhtasari | 189.75(W)×149.4(H) ×5.3(D) mm |
| mwangaza | 1000 cd/m² (Typ.) |
| angle ya kutazama | 75/75/60/70 (Typ.)(CR≥10) |
| mwonekano bora zaidi | - |
| kuonyesha rangi | 262K/16.7M |
| masafa | 60Hz |
| uzito | TBD |
| mfano wa paneli | AM-800600MTMQW-50H |
| aina ya paneli | a-Si TFT-LCD , LCM |
| muundo wa pixel | RGB Vertical Stripe |
| ufunguzi wa bezel | 173.4(W)×130.8(H) mm |
| uso | - |
| uwiano wa utofautishaji | 600:1 (Typ.) (TM) |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| wakati wa majibu | 8 (Typ.)(Tr+Td) |
| aina ya taa | 6S5P WLED , Without Driver |
| skrini ya kugusa | Without |
| maombi | Industrial Outdoor High Brightness |
| AA084SA01 | Mitsubishi | 8.4 | 800×600 |
| AM-800600M3TNQW-00H | AMPIRE | 8.4 | 800×600 |
| AM-800600M3TNQW-01H-F | AMPIRE | 8.4 | 800×600 |
| G084SN05 V3 | AUO | 8.4 | 800×600 |
| G084SN05 V7 | AUO | 8.4 | 800×600 |
| LQ084S3LG03 | SHARP | 8.4 | 800×600 |
| LTA084C190F | TOSHIBA | 8.4 | 800×600 |
| LTA084C274F | TOSHIBA | 8.4 | 800×600 |
| NL6448BC26-08D | NLT | 8.4 | 640×480 |
| NL6448BC26-09C | NLT | 8.4 | 640×480 |
