| Nambari ya Sehemu | AT070WSM-NW2 |
| Chapa | BOE |
| Ukubwa | 7.0 |
| Maombi | Automotive Display |
| Azimio | 1024×600 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 800:1 |
| Rangi | 262K/16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | |
| chapa | BOE |
| mfano | AT070WSM-NW2 |
| ukubwa wa diagonal | 7.0 inch |
| aina | a-Si TFT-LCD, LCM |
| muundo wa pixel | 1024(RGB)×600 [WSVGA] 170PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 154.214(H)×85.92(V) mm |
| muhtasari dim. | - |
| mwangaza | - |
| uwiano wa utofautishaji | 800:1 (Typ.) (TM) |
| tazama mwelekeo | - |
| wakati wa majibu | 25 (Typ.)(Tr+Tf) |
| angle ya kutazama | 80/80/60/70 (Typ.)(CR≥10) |
| hali ya uendeshaji | TN, Normally White, Transmissive |
| rangi ya msaada | 262K/16.7M 50% NTSC |
| chanzo cha mwanga | WLED |
| uzito | - |
| iliyoundwa kwa ajili ya | Automotive Display |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | Without |
| mazingira | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| AT070TN92 V.X | Innolux | 7.0 | 800×480 |
| B070ATN01.0 | AUO | 7.0 | 1024×600 |
| BP070HD1-100 | BOE | 7.0 | 720×1280 |
| C070FW03 V0 | AUO | 7.0 | 480×234 |
| C070VW03 V0 | AUO | 7.0 | 800×480 |
| CLAA070LC0ACW | CPT | 7.0 | 800×480 |
| CLAA070LC0CCW | CPT | 7.0 | 800×480 |
| LB070WQ6-TD01 | LG Display | 7.0 | 400×234 |
| LD070WS2-SL07 | LG Display | 7.0 | 1024×600 |
| ZJ070NA-01P | Innolux | 7.0 | 1024×600 |
