AT080TN42 V.1

AT080TN42 V.1
AT080TN42 V.1
AT080TN42 V.1
AT080TN42 V.1 thumb AT080TN42 V.1 thumb AT080TN42 V.1 thumb
Chapa
Innolux
Ukubwa
8.0
Maombi
CNS
Azimio
800×600
Muundo
LCM
Mwangaza
250
CR
500:1
Rangi
262K
Mwangaza nyuma
WLED
Kiolesura
TTL
In Stock
493
Vipimo

Nambari ya Sehemu AT080TN42 V.1
ChapaInnolux
Ukubwa8.0
MaombiCNS
Azimio800×600
MuundoLCM
Mwangaza250
CR500:1
Rangi262K
Mwangaza nyumaWLED
KiolesuraTTL
chapa ya paneliINNOLUX
mfano wa paneliAT080TN42 V.1
aina ya paneli a-Si TFT-LCD , LCM
saizi ya paneli8.0 inch
azimio800(RGB)×600 , SVGA
hali ya kuonyeshaTN, Normally White, Transmissive
eneo la kazi162×121.5 mm
muhtasari183×141 mm
usoAntiglare
mwangaza250 cd/m² (Typ.)
uwiano wa utofautishaji500:1 (Typ.)
kuonyesha rangi262K (6-bit)
wakati wa majibu10/15 (Typ.)(Tr/Td)
angle ya kutazama70/70/50/70 (Typ.)(CR≥10)(L/R/U/D)
aina ya taa3S9PWLEDWithout Driver
kiolesura cha isharaParallel RGB (1 ch, 6-bit), 60 pins
voltage ya pembejeo3.3/10.4/16.0/-7.0V (Typ.)(VCC/AVDD/VGH/VGL)
rohs:
maombiCNS
