| Nambari ya Sehemu | B101XAN02.0 |
| Chapa | AUO |
| Ukubwa | 10.1 |
| Maombi | PAD |
| Azimio | 1366×768 |
| Muundo | LCM |
| Mwangaza | 250 |
| CR | 800:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | MIPI |
| chapa ya paneli | AUO |
| mfano wa paneli | B101XAN02.0 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 10.1 inch |
| azimio | 1366(RGB)×768 , WXGA |
| hali ya kuonyesha | AHVA, Normally Black, Transmissive |
| eneo la kazi | 222.341×125.568 mm |
| muhtasari | 235.01×138.95×4.7 mm |
| uso | Glare (Haze 0%), Hard coating (3H) |
| mwangaza | 250 cd/m² (Typ.) |
| uwiano wa utofautishaji | 800:1 (Typ.) |
| kuonyesha rangi | 16.7M (6-bit + Hi-FRC), CIE193150% |
| wakati wa majibu | 15/10 (Typ.)(Tr/Td) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 4 stringsWLEDWithout Driver |
| kiolesura cha ishara | MIPI (4 data lanes), 39 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | PAD |
| B101AW03 V0 | AUO | 10.1 | 1024×600 |
| B101EW05 V1 | AUO | 10.1 | 1280×800 |
| B101XAN01.3 | AUO | 10.1 | 1366×768 |
| B101XAN02.0 | AUO | 10.1 | 1366×768 |
| B101XTN01.1 | AUO | 10.1 | 1366×768 |
| BP101WX1-100 | BOE | 10.1 | 1280×800 |
| BT101IW02 V.0 | Innolux | 10.1 | 1024×600 |
| DLC1010AZG-1 | Other | 10.1 | 1024×600 |
| G101EVN01.3 | AUO | 10.1 | 1280×800 |
| HSD101PWW1-G10 | HannStar | 10.1 | 1280×800 |
| B080UAN01.2 | AUO | 8.0 | 1200×1920 |
| B101EAN01.7 | AUO | 10.1 | 1280×800 |
| CLAA070WP03 | CPT | 7.0 | 800×1280 |
| ED090NA-01H | Innolux | 9.0 | 1280×800 |
| HT121WX2-211 | HYDIS | 12.1 | 1280×800 |
| HV121WX6-111 | HYDIS | 12.1 | 1280×800 |
| LP125WH2-SPM2 | LG Display | 12.5 | 1366×768 |
| LTL070AL03 | Samsung | 7.0 | 800×1280 |
| VVX07F023B00 | Panasonic | 7.0 | 1200×1920 |
| YXD090TN02-40NM01 | SEBO | 9.0 | 1280×800 |
