| Nambari ya Sehemu | B101XAN01.3 |
| Chapa | AUO |
| Ukubwa | 10.1 |
| Maombi | PAD |
| Azimio | 1366×768 |
| Muundo | CELL |
| Mwangaza | 0 |
| CR | 900:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | No B/L |
| Kiolesura | LVDS |
| chapa ya paneli | AUO |
| mfano wa paneli | B101XAN01.3 |
| aina ya paneli | a-Si TFT-LCD , CELL |
| saizi ya paneli | 10.1 inch |
| azimio | 1366(RGB)×768 , WXGA |
| hali ya kuonyesha | AHVA, Normally Black, Transmissive |
| eneo la kazi | 222.52×125.11 mm |
| muhtasari | 230.62×135.81×0.805 mm |
| uso | Hard coating, Antireflection |
| kioo kina | 0.25+0.25 mm |
| uwiano wa utofautishaji | 900:1 (Typ.) |
| kuonyesha rangi | 16.7M (6-bit + Hi-FRC), CIE193150% |
| wakati wa majibu | 25 (Typ.)(Tr+Td) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| kiolesura cha ishara | LVDS (1 ch, 8-bit), 40 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | PAD |
