| Nambari ya Sehemu | B116XAB01.3 |
| Chapa | AUO |
| Ukubwa | 11.6 |
| Maombi | Laptop |
| Azimio | 1366×768 |
| Muundo | a-Si TFT-LCD, Assemb |
| Mwangaza | |
| CR | 800:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | eDP |
| chapa | AUO |
| mfano | B116XAB01.3 (AUO288C) |
| ukubwa wa diagonal | 11.6 inch |
| aina | a-Si TFT-LCD, Assembly |
| muundo wa pixel | 1366(RGB)×768 [WXGA] 135PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 256.125(H)×144(V) mm |
| muhtasari dim. | 284.85(H)×189.84(V) ×4.2(D) mm |
| eneo la bezel | - |
| matibabu | Glare (Haze 0%), Hard coating (7H) |
| mwangaza | 220 cd/m² (Typ.) |
| uwiano wa utofautishaji | 800:1 (Typ.) (TM) |
| tazama mwelekeo | Symmetry |
| wakati wa majibu | 27 (Typ.)(Tr+Td) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| hali ya uendeshaji | - |
| rangi ya msaada | 16.7M 50% NTSC |
| chanzo cha mwanga | WLED , 15K hours , With LED Driver |
| mtindo wa fomu | - |
| iliyoundwa kwa ajili ya | Laptop |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | On-Cell Touch |
| aina ya kiolesura | eDP (2 Lanes) , eDP1.2 , 40 pins Connector |
| usambazaji wa nguvu | 3.3V (Typ.) |
| mazingira | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
