| Nambari ya Sehemu | B116XAN01.0 |
| Chapa | AUO |
| Ukubwa | 11.6 |
| Maombi | PAD |
| Azimio | 1366×768 |
| Muundo | LCM |
| Mwangaza | 700 |
| CR | 800:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | MIPI |
| chapa ya paneli | AUO |
| mfano wa paneli | B116XAN01.0 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 11.6 inch |
| azimio | 1366(RGB)×768 , WXGA |
| hali ya kuonyesha | AHVA, Normally Black, Transmissive |
| eneo la kazi | 256.125×144 mm |
| muhtasari | 267.17×157.31×4.74 mm |
| uso | |
| mwangaza | 700 cd/m² (Typ.) |
| uwiano wa utofautishaji | 800:1 (Min.) |
| kuonyesha rangi | 16.7M (8-bit), CIE193150% |
| wakati wa majibu | 30 (Max.)(Tr+Td) |
| angle ya kutazama | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 8S6PWLEDWithout Driver |
| kiolesura cha ishara | MIPI (4 data lanes), 45 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | PAD |
