| Nambari ya Sehemu | EE090NA-01C |
| Chapa | Innolux |
| Ukubwa | 9.0 |
| Maombi | PAD |
| Azimio | 1280×800 |
| Muundo | CELL |
| Mwangaza | 0 |
| CR | 700:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | No B/L |
| Kiolesura | TTL |
| chapa ya paneli | CHIMEI INNOLUX |
| mfano wa paneli | EE090NA-01C |
| aina ya paneli | a-Si TFT-LCD , CELL |
| saizi ya paneli | 9.0 inch |
| azimio | 1280(RGB)×800 , WXGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 193.92×121.2 mm |
| muhtasari | 201.46×130.66 mm |
| uso | |
| kioo kina | 0.50+0.50 mm |
| uhamishaji | 3.39% (Typ.)(with APCF) |
| uwiano wa utofautishaji | 700:1 (Typ.) |
| kuonyesha rangi | 16.7M (8-bit), CIE193170% |
| wakati wa majibu | 10/15 (Typ.)(Tr/Td) |
| angle ya kutazama | 70/70/70/50 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| kiolesura cha ishara | Parallel RGB (1 ch, 8-bit), 102 pins |
| voltage ya pembejeo | 3.3/11.0/20.0/-6.8V (Typ.)(DVDD/AVDD/VGH/VHL) |
| maombi | PAD |
