| Nambari ya Sehemu | B116XAN04.0 HW1A |
| Chapa | AUO |
| Ukubwa | 11.6 |
| Maombi | Laptop |
| Azimio | 1366×768 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 800:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | eDP |
| chapa | AUO |
| mfano | B116XAN04.0 HW1A (AUO405C) |
| ukubwa wa diagonal | 11.6 inch |
| aina | a-Si TFT-LCD, LCM |
| muundo wa pixel | 1366(RGB)×768 [WXGA] 135PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 256.125(H)×144(V) mm |
| muhtasari dim. | 278(H)×168(V) ×3(D) mm |
| eneo la bezel | - |
| matibabu | Antiglare, Hard coating (3H) |
| mwangaza | 220 cd/m² (Typ.) |
| uwiano wa utofautishaji | 800:1 (Typ.) (TM) |
| tazama mwelekeo | Symmetry |
| wakati wa majibu | 27 (Typ.)(Tr+Tf) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| hali ya uendeshaji | AHVA, Normally Black, Transmissive |
| rangi ya msaada | 262K 50% NTSC |
| chanzo cha mwanga | WLED , 15K hours , With LED Driver |
| mtindo wa fomu | Slim (PCBA Flat, T≤3.2mm) |
| iliyoundwa kwa ajili ya | Laptop |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | Without |
| aina ya kiolesura | eDP (1 Lane) , eDP1.2 , 30 pins Connector |
| usambazaji wa nguvu | 3.3V (Typ.) |
| mazingira | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| B116HAT03.1 | AUO | 11.6 | 1920×1080 |
| B116XAN01.0 | AUO | 11.6 | 1366×768 |
| B116XAN03.0 HW3A | AUO | 11.6 | 1366×768 |
| B116XAN03.1 HW0A | AUO | 11.6 | 1366×768 |
| B116XAN03.1 HW1A | AUO | 11.6 | 1366×768 |
| B116XTN01.0 HW1A | AUO | 11.6 | 1366×768 |
| B116XW05 V001 | AUO | 11.6 | 1366×768 |
| HN116WX1-203 | BOE | 11.6 | 1366×768 |
| LP116WH4-SLN1 | LG Display | 11.6 | 1366×768 |
| N116B6-L02 | Innolux | 11.6 | 1366×768 |
