| Nambari ya Sehemu | C090EAN01.0 |
| Chapa | AUO |
| Ukubwa | 9.0 |
| Maombi | Automotive Display |
| Azimio | 1280×720 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa | AUO |
| mfano | C090EAN01.0 |
| ukubwa wa diagonal | 9.0 inch |
| aina | a-Si TFT-LCD, LCM |
| muundo wa pixel | 1280(RGB)×720 [WXGA] 163PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 198.72(H)×111.78(V) mm |
| muhtasari dim. | - |
| mwangaza | - |
| uwiano wa utofautishaji | 1000:1 (Typ.) (TM) |
| tazama mwelekeo | Symmetry |
| wakati wa majibu | 15/15 (Max.)(Tr/Td) |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10) |
| hali ya uendeshaji | AHVA, Normally Black, Transmissive |
| rangi ya msaada | 16.7M 70% NTSC |
| chanzo cha mwanga | WLED |
| uzito | - |
| iliyoundwa kwa ajili ya | Automotive Display |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | Without |
| aina ya kiolesura | LVDS (1 ch, 8-bit) |
| mazingira | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 2.9G (28.4 m/s²) |
