| Nambari ya Sehemu | C123VAN01.0 |
| Chapa | AUO |
| Ukubwa | 12.3 |
| Maombi | Automotive Display |
| Azimio | 1440×540 |
| Muundo | a-Si TFT-LCD , LCM |
| Mwangaza | |
| CR | |
| Rangi | 16.7M |
| Mwangaza nyuma | - |
| Kiolesura | RSDS |
| chapa ya paneli | AUO |
| saizi ya paneli | 12.3" |
| azimio | 1440(RGB)×540, 125PPI |
| eneo la maonyesho | 291.6(W)×109.35(H) mm |
| saizi ya muhtasari | 308.5(W)×129(H) mm |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10) |
| mwonekano bora zaidi | Symmetry |
| kuonyesha rangi | 16.7M |
| masafa | 60Hz |
| uzito wa paneli | 580±58g |
| kiolesura cha ishara | RSDS (1 Channel) FPC |
| mazingira | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C |
| mfano wa paneli | C123VAN01.0 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| muundo wa pixel | RGB Vertical Stripe |
| ufunguzi wa bezel | 294.8(W)×112.35(H) mm |
| uso | Antiglare, Hard coating (3H) |
| hali ya kuonyesha | AHVA, Normally Black, Transmissive |
| wakati wa majibu | - |
| aina ya taa | |
| skrini ya kugusa | Without |
| maombi | Automotive Display |
| AV123Z7M-N11 | BOE | 12.3 | 1920×720 |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
