| Nambari ya Sehemu | CLAA102NB01XV |
| Chapa | CPT |
| Ukubwa | 10.2 |
| Maombi | IA |
| Azimio | 1024×600 |
| Muundo | LCM |
| Mwangaza | 400 |
| CR | 700:1 |
| Rangi | 262K/16.2M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | CPT |
| mfano wa paneli | CLAA102NB01XV |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 10.2 inch |
| azimio | 1024(RGB)×600 , WSVGA |
| hali ya kuonyesha | HFFS, Normally Black, Transmissive |
| eneo la kazi | 222.72×130.5 mm |
| muhtasari | 235×147×5.4 mm |
| uso | Antiglare |
| mwangaza | 400 cd/m² (Typ.) |
| uwiano wa utofautishaji | 700:1 (Typ.) |
| kuonyesha rangi | 262K/16.2M (6-bit / 6-bit + FRC), CIE193160% |
| wakati wa majibu | 30 (Typ.)(Tr+Td) |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 4S12PWLEDWithout Driver |
| kiolesura cha ishara | LVDS (1 ch, 8-bit), 60 pins |
| voltage ya pembejeo | 3.3/13/18/-6V (Typ.)(VDD/AVDD/VGH/VGL) |
| maombi | IA |
