| Nambari ya Sehemu | DD070NA-02C |
| Chapa | Chimei Innolux |
| Ukubwa | 7.0 |
| Maombi | Automotive Display |
| Azimio | 800×480 |
| Muundo | LCM , a-Si TFT-LCD |
| Mwangaza | |
| CR | 1600:1 |
| Rangi | 262K/16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | CMOS |
| mtengenezaji | Chimei Innolux |
| ukubwa wa skrini | 7.0 inch |
| nambari ya pixel | 800(RGB)×480 (WVGA) 133PPI |
| eneo amilifu(mm) | 152.4 × 91.44 (H×V) |
| eneo la bezel(mm) | 154.4 × 94.34 (H×V) |
| mwangaza | 400 cd/m² (Typ.) |
| angle ya kutazama | 70/70/60/60 (Typ.)(CR≥10) |
| mtazamo mzuri | 12 o'clock |
| kina cha rangi | 262K/16.7M 74% NTSC |
| wingi | 232±23g |
| kiwango cha upya | 60Hz |
| aina ya ishara | CMOS (1 ch, 6/8-bit) , 60 pins FPC |
| usambazaji wa voltage | 3.3/3.3/10/19/-6.8V (Typ.)(VCC/VDDG/AVDD/VGH/VGL) |
| max. ukadiriaji | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| jina la mfano | DD070NA-02C |
| aina ya skrini | LCM , a-Si TFT-LCD |
| mpangilio | RGB Vertical Stripe |
| muhtasari(mm) | 169.96 × 106.64 × 32.1 (H×V×D) |
| matibabu | Antiglare, Hard coating (3H) |
| uwiano wa utofautishaji | 1600 : 1 (Typ.) (TM) |
| majibu | 5/11 (Typ.)(Tr/Td) ms |
| hali ya kazi | TN, Normally White, Transmissive |
| backlight | WLED , 30K hours , No Driver |
| kutumika kwa | Automotive Display |
| skrini ya kugusa | 4-wire Resistive Touch |
| A070PAN01.0 | AUO | 7.0 | 900×1440 |
| AM-800480RWTMQW-TA4H | AMPIRE | 7.0 | 800×480 |
| BP070WX1-300 | BOE | 7.0 | 800×1280 |
| CLAA070ND26CW | CPT | 7.0 | 1024×600 |
| CLAA070NP01 | CPT | 7.0 | 1024×600 |
| DD070NA-02A | Innolux | 7.0 | 800×480 |
| ED070NA-01N | Innolux | 7.0 | 1024×600 |
| G070VTT01.0 | AUO | 7.0 | 800×480 |
| LQ070Y3DG02 | SHARP | 7.0 | 800×480 |
| LTA070B2C0F | TOSHIBA | 7.0 |
