| Nambari ya Sehemu | BP070WX1-300 |
| Chapa | BOE |
| Ukubwa | 7.0 |
| Maombi | PAD |
| Azimio | 800×1280 |
| Muundo | LCM |
| Mwangaza | |
| CR | |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | MIPI |
| chapa ya paneli | BOE |
| mfano wa paneli | BP070WX1-300 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 7.0 inch |
| azimio | 800(RGB)×1280 , WXGA |
| hali ya kuonyesha | AFFS, Normally Black, Transmissive |
| eneo la kazi | 94.2×150.72 mm |
| muhtasari | 99.7×160.93×3.8 mm |
| uso | Hard coating (3H), Antireflection |
| mwangaza | |
| uwiano wa utofautishaji | |
| kuonyesha rangi | 16.7M (6-bit + Hi-FRC), CIE193150% |
| wakati wa majibu | 30 (Typ.)(Tr+Td) |
| angle ya kutazama | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 5S4PWLEDWithout Driver |
| kiolesura cha ishara | MIPI, 34 pins |
| voltage ya pembejeo | 1.8/3.3V (Typ.)(IOVCC/VDD) |
| maombi | PAD |
| AT070TNA2 | Innolux | 7.0 | 1024×600 |
| BP070WS1-102 | BOE | 7.0 | 1024×600 |
| BP070WS1-200 | BOE | 7.0 | 1024×600 |
| BP070WS1-400 | BOE | 7.0 | 1024×600 |
| BP070WS1-500 | BOE | 7.0 | 1024×600 |
| BP070WSA-400 | BOE | 7.0 | 1024×600 |
| BP070WX1-100 | BOE | 7.0 | 1280×800 |
| BP070WX1-300 | BOE | 7.0 | 800×1280 |
| BP070WX6-400 | BOE | 7.0 | 800×1280 |
| C070VW03 V0 | AUO | 7.0 | 800×480 |
| B080EAN01.1 | AUO | 8.0 | 800×1280 |
| B101EAN01.2 | AUO | 10.1 | 1280×800 |
| B101UAN02.1 | AUO | 10.1 | 1920×1200 |
| HSD101PHW1-A00 | HannStar | 10.1 | 1366×768 |
| HV101WU1-1E3 | HYDIS | 10.1 | 1920×1200 |
| HX121WX1-111 | HYDIS | 12.1 | 1280×800 |
| LP097QX1-SPA1 | LG Display | 9.7 | 2048×1536 |
| N080ICE-GB0 Rev.B1 | Innolux | 8.0 | 800×1280 |
| N080ICE-GB0 Rev.C1 | Innolux | 8.0 | 800×1280 |
| TM090JDH01 | Tianma | 9.0 | 1280×800 |
