| Nambari ya Sehemu | DLC1040ABG-3 |
| Chapa | Other |
| Ukubwa | 10.4 |
| Maombi | IA |
| Azimio | 800×600 |
| Muundo | LCM |
| Mwangaza | 1000 |
| CR | 800:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | DLC |
| mfano wa paneli | DLC1040ABG-3 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 10.4 inch |
| azimio | 800(RGB)×600 , SVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 211.2×158.4 mm |
| muhtasari | 236×176.9×5.9 mm |
| uso | |
| mwangaza | 1000 cd/m² (Typ.) |
| uwiano wa utofautishaji | 800:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit), CIE193153% |
| wakati wa majibu | 30 (Typ.)(Tr+Td) |
| angle ya kutazama | 70/70/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | WLEDWithout Driver |
| kiolesura cha ishara | LVDS (1 ch, 6-bit), 20 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | IA |
| DLC1040ABG-2 | Other | 10.4 | 800×600 |
| DLC1040ABG-3 | Other | 10.4 | 800×600 |
| DLC1040ABG-T | Other | 10.4 | 800×600 |
| DLC1040ABG-T-2 | Other | 10.4 | 800×600 |
| EL640.480-AA1 | Lumineq | 10.4 | 640×480 |
| LQ104S1DG21 | SHARP | 10.4 | 800×600 |
| LTA104D182F | TOSHIBA | 10.4 | 800×600 |
| LTD104C11Z | TOSHIBA | 10.4 | 640×480 |
| LTD121EDKP | TOSHIBA | 10.4 | 1024×768 |
| NL8060BC26-11 | NLT | 10.4 | 800×600 |
| AT104XH11 | Mitsubishi | 10.4 | 1024×768 |
| LM10V332 | SHARP | 10.4 | 640×480 |
| LQ121S1LG41 | SHARP | 12.1 | 800×600 |
| LQ231U1LW21 | SHARP | 23.1 | 1600×1200 |
| MD400F640PD5 | Panasonic | 9.8 | 640×400 |
| PD064VXC | E Ink | 6.4 | 640×480 |
| RGS32256064WH002 | RiTdisplay | 3.2 | 256×64 |
| SX19V007 | KOE | 7.5 | 640×480 |
| T-51750GD065J-FW-ADN | Kyocera | 6.5 | 640×480 |
| UG-2864KLBMG01 | WiseChip | 1.54 | 128×64 |
