| Nambari ya Sehemu | EV101WUM-N20 |
| Chapa | BOE |
| Ukubwa | 10.1 |
| Maombi | Medical Imaging |
| Azimio | 1920×1200 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 900:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa | BOE |
| mfano | EV101WUM-N20 |
| ukubwa wa diagonal | 10.1 inch |
| aina | a-Si TFT-LCD, LCM |
| muundo wa pixel | 1920(RGB)×1200 [WUXGA] 224PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 216.806(H)×135.504(V) mm |
| muhtasari dim. | 229.45(H)×149.22(V) mm |
| mwangaza | 600 cd/m² (Typ.) |
| uwiano wa utofautishaji | 900:1 (Typ.) (TM) |
| tazama mwelekeo | Symmetry |
| wakati wa majibu | 30 (Typ.)(Tr+Td) |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10) |
| hali ya uendeshaji | ADS, Normally Black, Transmissive |
| rangi ya msaada | 16.7M 72% NTSC |
| chanzo cha mwanga | WLED , W/O Driver |
| uzito | - |
| iliyoundwa kwa ajili ya | Medical Imaging |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | Without |
| aina ya kiolesura | LVDS (1 ch, 8-bit) , 45 pins Connector |
| usambazaji wa nguvu | 3.3V (Typ.) |
| mazingira | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -25 ~ 80 °C |
