| Nambari ya Sehemu | HGS128647-Y-EH-LV |
| Chapa | Other |
| Ukubwa | 1.54 |
| Maombi | IA |
| Azimio | 128×64 |
| Muundo | OLED |
| Mwangaza | 150 |
| CR | 2000:1 |
| Rangi | Mono(Yellow) |
| Mwangaza nyuma | self |
| Kiolesura | CPU/SPI/I²C |
| chapa ya paneli | TSINGTEK |
| mfano wa paneli | HGS128647-Y-EH-LV |
| aina ya paneli | PM-OLED , OLED |
| saizi ya paneli | 1.54 inch |
| azimio | 128×64 |
| eneo la kazi | 35.056×17.52 mm |
| muhtasari | 54×39.5×8.5 mm |
| uso | |
| mwangaza | 150 cd/m² (Typ.) |
| uwiano wa utofautishaji | 2000 : 1 (Min.) |
| kuonyesha rangi | Mono(Yellow) |
| angle ya kutazama | 80/80/80/80 (Min.)(L/R/U/D) |
| dereva ic | Built-in SSD1305 |
| kiolesura cha ishara | 8-bit 6800/8080 parallel, 4-wire SPI, I²C, 20 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| rohs: | |
| maombi | IA |
