| Nambari ya Sehemu | HSD089IFW3-A00 |
| Chapa | HannStar |
| Ukubwa | 8.9 |
| Maombi | |
| Azimio | 1024×600 |
| Muundo | LCM |
| Mwangaza | 200 |
| CR | 500:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | HannStar |
| mfano wa paneli | HSD089IFW3-A00 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 8.9 inch |
| azimio | 1024(RGB)×600 , WSVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 195.072×113.4 mm |
| muhtasari | 213.66×129.85 mm |
| uso | |
| mwangaza | 200 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit), CIE193150% |
| wakati wa majibu | 12 (Typ.)(Tr+Td) |
| angle ya kutazama | 75/75/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| aina ya taa | WLED |
| kiolesura cha ishara | LVDS (1 ch, 6-bit), 40 pins |
| rohs: |
