| Nambari ya Sehemu | HSD090LFW1-B00 |
| Chapa | HannStar |
| Ukubwa | 9.0 |
| Maombi | Automotive Display |
| Azimio | 1024×600 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 800:1 |
| Rangi | 262K/16.2M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa | HannStar |
| mfano | HSD090LFW1-B00 |
| ukubwa wa diagonal | 9.0 inch |
| aina | a-Si TFT-LCD, LCM |
| muundo wa pixel | 1024(RGB)×600 [WSVGA] 132PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 196.608(H)×114.15(V) mm |
| muhtasari dim. | 211.1(H)×126.5(V) ×6(D) mm |
| eneo la bezel | 200.01(H)×117.55(V) mm |
| matibabu | Glare (Haze 0%) |
| mwangaza | 450 cd/m² (Typ.) |
| uwiano wa utofautishaji | 800:1 (Typ.) (TM) |
| tazama mwelekeo | Symmetry |
| wakati wa majibu | 17/18 (Typ.)(Tr/Td) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| hali ya uendeshaji | IPS Pro, Normally Black, Transmissive |
| rangi ya msaada | 262K/16.2M 50% NTSC |
| chanzo cha mwanga | WLED , 150K hours , W/O Driver |
| uzito | 230g (Typ.) |
| iliyoundwa kwa ajili ya | Automotive Display |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | Without |
| aina ya kiolesura | LVDS (1 ch, 6/8-bit) , 40 pins FPC |
| usambazaji wa nguvu | 3.3/12.5/23/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| mazingira | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C ; Vibration Level: 2.9G (28.4 m/s²) |
